The unsung hero of the Carli suspension lineup, the Signature Series suspension system packs an unbeatable improvement in ride quality per dollar spent. The heart of this system is the custom spec Carli Signature series shocks. These shocks are made by Carli with vehicle specific valving profiles, ti-nitride coated shafts, zinc plated and clear coated bodies, and included shock boots. In this system, they're paired with Carli's vehicle specific coils, which are available in both diesel and gas specs for 2017 and newer Ford Super Duty trucks.
This system levels the truck, increases front wheel travel to 9" and dramatically smooths ride on road and off road. To support that height and wheel travel increase, Carli includes a host of the highest quality USA made supporting parts like their stainless brake lines, caster shims to address caster specs, and their in house designed track bar. Carli's track bar centers the axle at the new ride height utilizing a stronger suspension/steering link to prevent death-wobble and improve overall tracking and steering feel.
While it isn't mandatory to add a rear option, we do recommend the add a pack for F-250 trucks to eliminate the factory block, and improve ride quality on large impacts without sacrificing payload.
If you don't add a rear Carli leaf spring option, certain 2020+ F-250s may need a taller rear block to sit level depending on the trim package. If you find your truck is rear low, we recommend this block kit.
A “Base Kit” SKU must be accompanied by the SKU of a Sway Bar Option to form a complete system.
This system fits Ford F-250 and Ford F-350 4x4 trucks from 2017 to Current
Please note if your truck is a 2023+ Platinum/Limited trim equipped with factory headlight angle / load scale sensors you will need these brackets to fix the sensors in place and remove the sensor linkage.
SPECIFICATIONS
-2.5" Front Lift / 3.5" on 2020+ Trucks
-Custom coil spring rate
-Maintains steering geometry
COMPONENTS
-Carli Front Ford Super Duty 2.5" Leveling Coils
-Carli 2017+ Ford Super Duty Adjustable Track Bar
-Carli 2017+ Ford Super Duty Front Stainless Braided Brake Lines
-Caster Correction Shims
-Carli Leveling Front Bump Stop Drops
OPTIONAL
-Carli 2017+ Ford Progressive Add-A-Packs & Rear Bump Drops
-Carli 2017+ Ford Full Progressive Rear Leaf Springs
-Carli Ford Super Duty Fabricated Radius Arms
APPLICATIONS
This kit will fit all 2017-2019 Ford F250/F350 Super Duty 4x4 pickups.
FITMENT GUIDE
Year Model Part Number
| F250/350 Lift Height | TREMOR Lift Height |
|---|---|
| 3.5″ | 1.5″ |
| Front Travel | Rear Travel |
|---|---|
| 9.6″ | 13″ |
| Shock Diameter | Tire Fitment |
|---|---|
| 2″ | 37″ x 12.5″ |
Customer Reviews
2023 F-250 Tremor. This kit is awesome! First off, I wasnt impressed by the look of the factory 35in tires on the Tremor, i wanted to go bigger after the level. This level lift made the 35's finally look like they belong there, saving me money for now to at least get some use out of the stock tires. This kit softens small bumps quite a bit, and handles real bumps and road obstructions like an 8000lb prerunner! Only downfall is the price, but to fully transform the ride of this amazing truck while still utilizing all the bells and whistles, I'm fully satisfied with these quality components and great new ride.
This is the best leveling kit I have used. The truck looks great, rides better then stock, and was super easy to install.
Second to none. All standards reference Carli.
CJC delivered as promised very pleased with the product. They sold what I needed rather than trying to up sale something that added no value to me. Thank you once again
