Carli's focus in building this control arm kit was to have the best product on the market. Carli's control arms are 1/2" longer than O.E.M and are built out of extremely stout box tubing. The box tubing's advantages over round tubing include a reduced control arm width while allowing the tube to be offset inboard for added tire clearance. Expertly welded to each square tube is a spherical joint that is fully serviceable and rebuildable. Having these spherical joints on each end eliminates the kinetic chatter caused by rubber bushing style set ups, in return creating a smoother ride. These control arms are finished off with a Satin Black powder coat to ensure long term protection from corrosion.
We offer the option to add hardware to these control arms. The two lower cam bolts are often frozen on the truck, meaning they have to be cut off to remove the arms. If you think yours are frozen, you’ll want to replace them. The upper bolt on the passenger side requires the removal of the exhaust down pipe, so we also highly recommend adding that bolt from the options as it makes the installation a whole lot faster if you can cut the stock bolt off and then insert the new one from the outside.
SPECIFICATIONS
-Box Tube Construction
-Maximum Tire Clearance
-Hardened Steel Joints
-Zerk Fittings For Easy Maintenance
-Manufactured In-House at Carli Suspension
-Sold as a set of 4 (2 upper, 2 lower)
FITMENT GUIDE
Year Model Part Number
2003-09 DODGE RAM 2500/3500 4x4 CS-CA-MS-03
2010-12 DODGE RAM 2500/3500 4x4 CS-CA-MS-10
Installation Instructions
Customer Reviews
Quality is phenomenal. They are expensive but very worth the price. Easy to install, look great and improved ride quality and handling response notably.
Ordered items 12/10/25
Called 12/20/25 didn’t get shipped till 12/22/25
Received 12/30/25
I delayed adding these to my Backcountry 2.0 suspension kit and frankly was a bit disappointed in the kit. Adding the arms definitely have noticed a better ride with the suspension package
Great help, great kit. Everything I was told was accurate and helpful. Kit changed my truck ride so much that its like a drive a whole new vehicle. It’s now fun to drive my 3/4 ton pick up.
Looks good, haven’t installed yet
