The Performance Series 2.0 IFP smooth body shocks contain the latest in shock technology to transform the performance of your Truck or SUV. They use our race-proven damping control to provide a comfortable on-road ride and predictable off-road handling in even the toughest conditions.
The precision metal impact aluminum body increases cooling capacity and will never rust. Inside you will find our race-proven performance valving technology. Our Internal Floating Piston (IFP) mono-tube design separates the shock oil from the high-pressure, nitrogen-charged gas chamber. The IFP eliminates oil aeration allowing maximum performance from the factory-tuned precision valving. The race developed high flow damping piston matched with application specific valving provides the Performance Series 2.0 IFP shock a predicable ride quality capable of handling the roughest road conditions.
| PART NUMBER | 985-24-151 |
| FEATURES | PERFORMANCE TUNED FOR VEHICLE SPECIFIC APPLICATION; ALUMINUM BODY DISSIPATES HEAT FASTER THAN STEEL; IFP SEPARATES OIL FROM HIGH-PRESSURE NITROGEN GAS; BLACK ANODIZED CNC MACHINED ALUMINUM COMPONENTS |
| SERIES | PERFORMANCE |
| TRAVEL | 11.61 |
| REAR LIFT HEIGHT | 0-1 |
| BODY | 2.0” IMPACT EXTRUDED AND CNC MACHINED 6061-T6 CLEAR ANODIZED ALUMINUM ONE-PIECE BODY RESISTS RUST OVER TIME |
| BODY PLATING | CLEAR-ANODIZED FOR A DURABLE FINISH |
| COMPONENTS | BLACK-ANODIZED, CNC-MACHINED 6061-T6 BILLET ALUMINUM |
| SHAFT | 5/8" HARD CHROME PLATED HEAT-TREATED ALLOY STEEL |
| PISTON | RACE-DEVELOPED HIGH-FLOW PISTON DESIGN |
| VALVING | APPLICATION SPECIFIC VALVING TO MAXIMIZE PERFORMANCE |
| SEALS | REDUNDANT SEALING PACK SYSTEM MAIN SEAL, WIPER SEAL, SCRAPER SEAL |
| EXTENDED LENGTH | 30.11 |
| COMPRESSED LENGTH | 18.5 |
| TOP MOUNT | EYELET |
| BOTTOM MOUNT | EYELET |
