Carli Suspension 2013+ 3500 Pintop King 2.5 Leveling System


Free Ships in 1-5 Business Days

Regular price $3,935.00 Save $-3,935.00

-16 in stock
USA MADE // Carli is committed to production in the USA. Every single Carli Product is American made and sourced, down to the tape and boxes themselves.
CUSTOM TUNED // Unlike your average lift, Carli Suspension uses only custom tuned shocks. Each shock package goes through months of testing, development, tuning, and valving. The Pintop level system features 2.5" diameter King shocks tuned for the best off road and on road performance possible with the factory rear spring to maintain factory payload/towing specs.
FABRICATED RADIUS ARMS // Hand fabricated and welded in California with the highest quality joints for improved flex, these arms are a high strength radius arm replacement. They also have more tire clearance than the factory arms thanks to a notched design. If you want the best of the best for your truck, look no further.
SWAY BAR UPGRADE // Eliminates the harshness caused by the stiff factory sway bar, letting your suspension do its job and move independently. This is one of the single biggest improvements you can make to your truck’s ride. To keep the factory ride, select the end link option. (TSB is for 03+ only)
Designed for anyone that needs to tow but wants the best ride possible, this system is designed to keep factory payload and towing specs with increased ride comfort.
Whether it's on road, towing, or in the dirt, there's no better riding system that can haul at factory spec. For those that love the way their Ram tows from the factory but don’t want to be limited to a crawl when leaving the pavement, this is the perfect kit.

The Details:

This system boasts Carli tuned King 2.5” shocks on all four corners. Carli also ships ALL King shocks with stainless shock shafts, so unlike King’s standard shafts, there is no coating to wear off. The included Adjustable Track Bar recenters the axle laterally at the taller ride height with only the highest quality joints available. We provide a 1″ rear lift block for the 2019+ platform (these trucks are 1″ lower in the rear than their 13-18 counterparts).

**This system will NOT be upgradeable to any other Carli Suspension Systems.** It’s designed to be a solution for customers wanting a quality, big-shock system boasting huge off-road capability, minimal lift and NO reduction in payload or hauling capacity. This system will result in tight and responsive, sports-car like handling; the 3” Suspension Systems will ride softer in the rear given the included reduced capacity rear springs.

This system fits Dodge Ram 3500 4x4 trucks from 2013 to current with factory rear leaf springs.

Front Lift Rear Lift Front Travel Rear Travel Shock Diameter Tire Fitment
2.5″ 0″ 8.3″ 11″ 2.0″ 35″ x 12.5″


SKU: CS-DPT25-LVL-19-D-3500
Ram Pintop 2.5" Leveling System, Diesel
2019+ 3500 4x4 SRW
2019+ 3500 4x4 DRW, use other option (CS-DPT25-LVL-13-D) with NO BLOCK

Ram Pintop 2.5" Leveling System, Diesel:
2013-18 3500, SRW & DRW
2019+ 3500 DRW ONLY

Installation Instructions

Customer Reviews

Based on 1 review
Nick Harrington
Amazing, it’s changed my trucks life.

Start with looks and ends with a smile. The ride is in between.
