This system is designed for the customer that keeps their truck on the pavement, but wants a better ride, level stance and more comfort on mild dirt roads. At the heart of this system is a 2.5” lift, Linear Rate Coil Spring paired to matched travel Fox 2.0” IFP Shocks that have been custom tuned by Carli for superior ride quality and handling. The rear shocks are also included with this system and have been custom tuned to maximize the ride quality for the factory rear leaf springs. In 2019, Ram lowered the rear of the 2500 trucks – for this reason, Carli is now providing a 1″ Billet Block and U-Bolts to fit the larger AAM 12″ Axle (4.25″ Axle Tubes). As the rear springs remain unmodified aside from the lift block, load capacity is maintained. For those that aren’t looking for massive increase in travel or big shocks but still desire a level stance and improved ride quality and handling characteristics, this is the perfect kit. The 2.5” lift height doesn’t require the geometry correction of our 3” Systems.
2019+ Ram 3500 single rear wheel (SRW) trucks will use the version with a block. All other trucks within the fitment range will not require a rear block.
The addition of a Carli Low-Mount Steering Stabilizer is recommended for any tire over factory size.
This system fits Dodge Ram 3500 4x4 trucks from 2013+ with factory rear leaf springs. THIS IS A DIESEL ONLY SYSTEM, if you have a gas truck please email us so we can get you set up with something that fits.
**This system will NOT be upgradeable to any other Carli Suspension Systems aside from the pintop level.** It’s designed to be a solution for customers wanting a quality system with minimal lift and part inclusion. This system is NOT compatible with trucks equipped with the factory auto-leveling air assist. For factory air trucks, we recommend this purpose built system. This system is not compatible with cab and chassis model trucks.
|Front Lift||Rear Lift||Front Travel||Rear Travel||Shock Diameter||Tire Fitment|
|2.5″||1″||8.3″||11″||2.0″||35″ x 12.5″|
These guys took perfect care of my issue and sent the products out FAST. A+++++ service and customer service. I will recommend
Title says it all. Install was a breeze, guy at the counter (Sorry I can’t remember your name) was very helpful. Clearing 37” Recon Grapplers on +18 wheels, with no rubbing on regular street driving. Only complaint is the price.
Love it. Rides great
Money well spent. The ride quality is amazing. What a difference from stock. Sits on 295/65/20
20×9 +18 offset XD wheels
And my order was processed and shipped exceptionally fast.
