Fox Factory Race Series 2.0 ATS Steering Stabilizer for 2014-2024 Dodge Ram 2500/3500

With conventional steering stabilizers, turning in one direction creates an increase in pressure inside the stabilizer as the shaft occupies more volume in the body and displaces the oil. The repercussion is a push or pull steering force felt by the driver as the stabilizer attempts to return to its neutral state. To overcome this unidirectional force, dual opposing stabilizers are often used, but this requires additional mounting hardware and space.

FITMENT: Does not fit the solid axle 2 wheel drive trucks, does not fit trucks with Carli track bar. We have seen instances of contact with Thuren track bars at full suspension compression. This stabilizer will ONLY work with factory linkage, and will not fit with Synergy, Apex or any other aftermarket steering.

The Factory Race Series 2.0 Stabilizer ATS utilizes an Adjustable Through Shaft (ATS) architecture that eliminates shaft fluid displacement throughout the stabilizer’s entire travel in both directions. By nature of that design, the stabilizer is completely neutral, with no push even at the most extreme ends of the travel. The external piggyback reservoir provides additional fluid capacity and utilizes an Internal Floating Piston (IFP) to separate the fluid from the nitrogen gas charge to eliminate cavitation. For increased control that can be tailored to any driving style and setup, an external adjuster provides 24 clicks of adjustment to fine tune the feel. The result is highly customizable and consistent damping of unwanted steering feedback in a single, bolt-on stabilizer.

The Factory Race Series 2.0 Stabilizer ATS includes application specific mounting hardware and is available in multiple clamp sizes for stock or aftermarket heavy duty tie-rods.

Features:

• Body - 2.0" impact extruded and CNC machined 6061-T6 anodized aluminum body resists rust over time
• Body Plating - Hard-anodized for a durable finish
• External Reservoir - External reservoir design separates shock oil from the high-pressure nitrogen
• Components - Black-anodized, CNC-machined 6061-T6 billet aluminum
• Shaft - 5/8" hard chrome plated heat-treated alloy steel
• Piston - Race-developed high-flow piston design
• Seals - Redundant sealing pack system main seal, wiper seal, scraper seal
• Oil - JM92 Advanced Suspension Fluid for improved performance at variable temperatures
• Adjustments - Adjuster - 24 clicks of adjustability
• Travel - 8.200"
• Compressed - 15.100"
• Extended - 23.300'
• Top Mount - Axle Mount
• Bottom Mount - Eyelet
