Carli Dodge Ram 2010-2013 2500/3500 3" Backcountry 2.0 Suspension System

Carli Dodge Ram 2010-2013 2500/3500 3" Backcountry 2.0 Suspension System - CJC Off Road

Carli Dodge Ram 2010-2013 2500/3500 3" Backcountry 2.0 Suspension System

Name: Carli Dodge Ram 2010-2013 2500/3500 3 Backcountry 2.0 Suspension System
Brand: Carli Suspension
SKU: CS-DBC20-10-D / CS-D3-BC-CS-10-D
Price: 2535.0 USD
Availability: InStock

CS-DBC20-10-D / CS-D3-BC-CS-10-D

Free Ships in 1-5 Business Days

$2,535.00

Quantity

USA MADE // Carli is committed to production in the USA. Every single Carli Product is American made and sourced, down to the tape and boxes themselves.

CUSTOM TUNED // Unlike your average lift, Carli Suspension uses only custom tuned shocks. Each shock package goes through months of testing, development, tuning, and valving. The Back Country system is tuned to be an all around set up bridging the gap between the Commuter and King shock systems. Have a truck that does 90% street duty with a little off road mixed in? This is the system for you.

CONTROL ARMS // Hand fabricated and welded in California with the highest quality joints for improved flex, these arms are a high strength control arm replacement. To run 37’s, you will need the high clearance fabricated arms that have a notch for tire clearance.

SWAY BAR UPGRADE // Eliminates the harshness caused by the stiff factory sway bar, letting your suspension do its job and move independently. This is one of the single biggest improvements you can make to your truck’s ride. To keep the factory ride, select the end link option. (TSB is for 03+ only)

LEAF PACK OPTIONS // Balancing ride and capability, the add a pack retains factory payload but improves small bump compliance by increasing the leaf count and reducing leaf thickness in half the pack. With the full leaf pack, a 15% payload reduction gets the best possible ride quality from the rear of the truck. Small chatter or large hit, this leaf pack will swallow it whole. The HD pack is ONLY for chase trucks or trucks with over 2,000lbs in bed at all times.

Carli's Backcountry 2.0 system is designed for people seeking the best ride on and off-road on a budget. The Back Country is made for anyone that wants to have a little dirt-road fun in their 8,500lb truck without losing the on-road ride quality or function. Utilizing custom Carli SPEC 2.0 Remote Reservoir Shocks, Carli has developed a shock tune that delivers all around comfort and ride quality designed for on-road, in town, highway, towing/hauling as well as slow to mid speed off road use. The Carli SPEC 2.0s are aluminum shocks that will stand the test of time, even when exposed to the elements. They’re constructed with bushings in the rod ends for long-lasting, maintenance free performance. This system rides best with the full progressive leaf springs and 17” or 18” wheels on, 35” Toyo M/T at 40F/35R. Both of the aforementioned are strongly suggested. We also recommend the purchase of a set of extended control arms to shift the axle forward to its new center of travel. High clearance arms are required to clear a 37” tire.

**2010-present vehicles have 2 possible sizes of Sway Bar End Links. Place a socket on the nut that compresses the rubber End Link bushings; fitment of an 18mm socket will indicate the need for the 12mm part number.

This system fits Dodge Ram 2500 and Dodge Ram 3500 4x4 trucks from 2010, 2011, 2012, 2013.

FEATURES

-Carli 3" Front Lift Coil Springs
-Carli Back Country 2.0 Shock Package with Limit Straps and Reservoir Mounts
-Carli Adjustable Track Bar

OPTIONAL

-Carli Stainless Sway Bar End Links With F.K. Bearings
-Carli Torsion Sway Bar
-Carli Adjustable Track Bar
-Carli Control Arms
-Carli Rear 5 Leaf Progressive Add a Packs
-Carli Full Progressive Rear Leaf Springs

FITMENT GUIDE

Year Model Part Number

2010-13 DODGE RAM 2500 4x4 Diesel (10mm End Links) CS-DBC20-10-D
2010-13 DODGE RAM 2500 4x4 Diesel (12mm End Links) CS-DBC20-10-D-12mm
2010-12 DODGE RAM 3500 4x4 Diesel (10mm End Links) CS-DBC20-10-D

2010-12 DODGE RAM 3500 4x4 Diesel (12mm End Links) CS-DBC20-10-D-12mm

2003-09 DODGE RAM 2500/3500 4x4 Diesel CS-DBC20-03-D

WHEEL/TIRE FITMENT

This system will fit up to a 35” tire with stock control arms on 17”-18” wheels with 5.75-6” of backspacing (including factory or near factory spec. wheels). We recommend running a wheel no more than 9” with 5.75” of backspacing with High Clearance Control arms and Full Replacement Leaf Springs to allow 37” tire fitment.

Installation Instructions

Great Investment for my Truck

I have a 2012 Ram 2500 Cummins with heavy aftermarket bumpers and a Warn 12k winch on the front. I had previously lifted the truck many years ago (I bought it new) but I was never happy with the ride of the truck on or off road. After doing a great deal of research I concluded that Carli was going to be the best avenue for me. More expensive - yes, but this is a truck I plan to keep for a long time and I look at it as an investment for the long term. I opted for Backcountry System along with new control arms and the full torsion sway bar. What an amazing ride! My truck rides like a brand new truck. So quiet, comfortable, predictable (none of the things I had before). I guess the word I would use to describe the feel is Glide. It is just such a smooth ride for a beast of a pickup. I also have a Leer topper on the back and the full drawer rollouts in the bed. I did not opt for the full leaf package because I want to see how it rides with the changes I made and with the weight already in the back.

Carli knows what they’re doing.

Nicest ride I’ve ever had. My truck feels luxury with this new suspension. Can’t recommend this kit and better from Carli.
