The Carli Back Country system is designed to be the jack of all trades. It's comfortable on the street, capable on the dirt, and still comes in at an attainable price. Unlike most systems on the market with Fox shocks, this Carli Back Country features Carli's proprietary tuned Fox 2.0 reservoir shocks front and rear, which are designated by a unique part number.
This system also features all the necessary supporting parts (many of which are skipped by other brands) to allow for double the factory suspension movement wile maintaining perfect factory geometry. No other system at this price-point is this comprehensive and addresses all the suspension vitals.
This system fits Dodge Ram 2500 4x4 trucks from 2014, 2015, 2016, 2017, 2018, 2019, 2020, 2021 and 2022 with factory rear coil springs.
This system will fit 35s with no trimming on a 0 to +27 offset wheel that is no wider than 9." To fit 37s on a Ram truck we recommend a +18 to +27 offset wheel that is no wider than 9,” as well as some mild trimming of the plastic fender liner and maybe pinch weld depending on the tire.
-Carli 2014+ Ram 2500 Back Country Fox 2.0 Reservoir Shock Package
-Carli Front Linear Rate 2014+ Ram 2500 Coil Springs
-Carli Rear Multi Rate 2014+ Ram 2500 Coil Springs
-Carli 2014+ Ram 2500 Adjustable Track Bar
-Carli 2014+ Ram 2500 Rear Track Bar Drop Bracket
-Carli 2014+ Ram 2500 Radius Arm Drop Brackets
-Carli Front Bump Stop Drops
-Carli 2014+ Ram 2500 Rear Sway Bar End Links
-Carli Front Billet Sway Bar Drop Brackets
-Carli 2014+ Ram 2500 Torsion Sway Bar
-Carli Ram Fabricated Radius Arms
-3" Front Lift
-1" Rear Lift
-Level Ride Height
-Unparalleled ride quality
-All inclusive system - no suspension upgrades required
-Most geometrically sound system on the market
-Coils have proper forces applied due to radius arm drop brackets
-Rear coil suspension "wag" is minimized
Year Model Part Number
2014-18 DODGE RAM 2500 4x4 Diesel CS-DBC20-1419-D
2014-18 DODGE RAM 2500 4x4 Hemi CS-DBC20-1419-H
|Front Lift||Rear Lift||Front Travel||Rear Travel||Shock Diameter||Tire Fitment|
|3.25″||1″||9.6″||11″||2.0″||35" / 37″|
