Carli Suspension 2014+ Dodge Ram 2500 Backcountry 2.0 3.25" Lift System

CS-DBC20-1419-D

Free Ships in 3-5 Business Days

Regular price $4,045.00 Save $-4,045.00

0 in stock
USA MADE // Carli is committed to production in the USA. Every single Carli Product is American made and sourced, down to the tape and boxes themselves.
CUSTOM TUNED // Unlike your average lift, Carli Suspension uses only custom tuned shocks. Each shock package goes through months of testing, development, tuning, and valving. The Back Country shocks are custom tuned to get the most all around performance at the lowest price. Whether it's on road driving or a day in the dirt, these shocks can handle it!
FABRICATED RADIUS ARMS // Hand fabricated and welded in California with the highest quality joints for improved flex, these arms are a high strength radius arm replacement. They also have more tire clearance than the factory arms thanks to a notched design. If you want the best of the best for your truck, look no further.
SWAY BAR UPGRADE // Eliminates the harshness caused by the stiff factory sway bar, letting your suspension do its job and move independently. This is one of the single biggest improvements you can make to your truck’s ride. To keep the factory ride, use either the drops or end links. The end links are prefered if you plan to upgrade to a torsion sway bar in the future.

The Carli Back Country system is designed to be the jack of all trades. It's comfortable on the street, capable on the dirt, and still comes in at an attainable price. Unlike most systems on the market with Fox shocks, this Carli Back Country features Carli's proprietary tuned Fox 2.0 reservoir shocks front and rear, which are designated by a unique part number.

This system also features all the necessary supporting parts (many of which are skipped by other brands) to allow for double the factory suspension movement wile maintaining perfect factory geometry. No other system at this price-point is this comprehensive and addresses all the suspension vitals.

This system fits Dodge Ram 2500 4x4 trucks from 2014, 2015, 2016, 2017, 2018, 2019, 2020, 2021 and 2022 with factory rear coil springs.

This system will fit 35s with no trimming on a 0 to +27 offset wheel that is no wider than 9." To fit 37s on a Ram truck we recommend a +18 to +27 offset wheel that is no wider than 9,” as well as some mild trimming of the plastic fender liner and maybe pinch weld depending on the tire.


INCLUDES

-Carli 2014+ Ram 2500 Back Country Fox 2.0 Reservoir Shock Package
-Carli Front Linear Rate 2014+ Ram 2500 Coil Springs
-Carli Rear Multi Rate 2014+ Ram 2500 Coil Springs
-Carli 2014+ Ram 2500 Adjustable Track Bar
-Carli 2014+ Ram 2500 Rear Track Bar Drop Bracket
-Carli 2014+ Ram 2500 Radius Arm Drop Brackets
-Carli Front Bump Stop Drops
-Carli 2014+ Ram 2500 Rear Sway Bar End Links

OPTIONAL

-Carli Front Billet Sway Bar Drop Brackets
-Carli 2014+ Ram 2500 Torsion Sway Bar
-Carli Ram Fabricated Radius Arms

SPECIFICATIONS

-3" Front Lift
-1" Rear Lift
-Level Ride Height
-Unparalleled ride quality
-All inclusive system - no suspension upgrades required
-Most geometrically sound system on the market
-Linear travel
-Coils have proper forces applied due to radius arm drop brackets
-Rear coil suspension "wag" is minimized

FITMENT GUIDE

Year
Model Part Number

2014-18 DODGE RAM 2500 4x4 Diesel CS-DBC20-1419-D
2014-18 DODGE RAM 2500 4x4 Hemi CS-DBC20-1419-H

Installation Instructions



Front Lift Rear Lift Front Travel Rear Travel Shock Diameter Tire Fitment
3.25″ 1″ 9.6″ 11″ 2.0″ 35" / 37″
